Texas Instruments TMS320F2810PBKA

Part No.:: TMS320F2810PBKA

Manufacturer:: Texas Instruments

Package:: 128-LQFP

Datasheet:

Description:: IC MCU 32BIT 128KB FLASH 128LQFP

In Stock:: 3482

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TMS320F2810PBKA Specifications

Package/Case:
128-LQFP
Packaging:
Tray
Series:
Automotive, AEC-Q100, C2000™ C28x Fixed-Point
RoHS:
RoHS
Speed:
150MHz
RAM Size:
18K x 16
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, McBSP, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
56
Core Processor:
C28x
Data Converters:
A/D 16x12b
Oscillator Type:
Internal
Program Memory Size:
128KB (64K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
