Texas Instruments TMS320F28075PZPS

Part No.:: TMS320F28075PZPS

Manufacturer:: Texas Instruments

Package:: 100-TQFP Exposed Pad

Datasheet:: TMS320F28075PZPS.pdf

Description:: IC MCU 32BIT 512KB FLSH 100HTQFP

In Stock:: 2623

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TMS320F28075PZPS Specifications

Package/Case:
100-TQFP Exposed Pad
Packaging:
Tray
Series:
C2000™ C28x Piccolo™, Functional Safety (FuSa)
RoHS:
RoHS
Speed:
120MHz
RAM Size:
50K x 16
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, I²C, McBSP, SCI, SPI, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
41
Core Processor:
C28x
Data Converters:
A/D 14x12b; D/A 3x12b
Oscillator Type:
External
Program Memory Size:
512KB (256K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TJ)
