Texas Instruments TM4C123GH6PZT

Part No.:: TM4C123GH6PZT

Manufacturer:: Texas Instruments

Package:: 100-LQFP

Datasheet:: TM4C123GH6PZT.pdf

Description:: IC MCU 32BIT 256KB FLASH 100LQFP

In Stock:: 3696

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TM4C123GH6PZT Specifications

Package/Case:
100-LQFP
Packaging:
Tray
Series:
Tiva™ C
RoHS:
RoHS
Speed:
80MHz
RAM Size:
32K x 8
Core Size:
32-Bit
EEPROM Size:
2K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, Motion PWM, POR, WDT
Connectivity:
CANbus, I²C, IrDA, Microwire, QEI, SPI, SSI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
69
Core Processor:
ARM® Cortex®-M4F
Data Converters:
A/D 22x12b
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
