Toshiba Semiconductor and Storage TLP187(TPL,E

Part No.:: TLP187(TPL,E

Manufacturer:: Toshiba Semiconductor and Storage

Package:: 6-SOIC (0.173, 4.40mm Width), 4 Leads

Datasheet:: TLP187(TPL,E.pdf

Description:: OPTOISO 3.75KV DARL 6-SO, 4 LEAD

In Stock:: 2931

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLP187(TPL,E Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
NumberofChannels:
1
Voltage-Isolation:
3750Vrms
CurrentTransferRatio(Min):
1000% @ 1mA
CurrentTransferRatio(Max):
-
TurnOn/TurnOffTime(Typ):
50µs, 15µs
Rise/FallTime(Typ):
40µs, 15µs
InputType:
DC
OutputType:
Darlington
Voltage-Output(Max):
300V
Current-Output/Channel:
150mA
Voltage-Forward(Vf)(Typ):
1.25V
Current-DCForward(If)(Max):
50 mA
VceSaturation(Max):
1.2V
OperatingTemperature:
-55°C ~ 110°C
MountingType:
Surface Mount
