Texas Instruments TLC6C5724QDAPRQ1

Part No.:: TLC6C5724QDAPRQ1

Manufacturer:: Texas Instruments

Package:: 38-PowerTSSOP (0.240, 6.10mm Width)

Datasheet:: TLC6C5724QDAPRQ1.pdf

Description:: IC LED DRV LIN PWM 50MA 38HTSSOP

In Stock:: 3341

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLC6C5724QDAPRQ1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100
ProductStatus:
Active
Type:
Linear
Topology:
-
InternalSwitch(s):
No
NumberofOutputs:
24
Voltage-Supply(Min):
3V
Voltage-Supply(Max):
5.5V
Voltage-Output:
8V
Current-Output/Channel:
50mA
Frequency:
4MHz, 8MHz
Dimming:
PWM
Applications:
Automotive, Backlight, Lighting
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
