Texas Instruments TCA9517DR

Part No.:: TCA9517DR

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: TCA9517DR.pdf

Description:: IC TRNSLTR BIDIRECTIONAL 8SOIC

In Stock:: 2225

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TCA9517DR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
TCA
ProductStatus:
Active
TranslatorType:
Voltage Level
ChannelType:
Bidirectional
NumberofCircuits:
1
ChannelsperCircuit:
2
Voltage-VCCA:
0.9 V ~ 5.5 V
Voltage-VCCB:
2.7 V ~ 5.5 V
InputSignal:
-
OutputSignal:
-
OutputType:
Open Drain
DataRate:
-
OperatingTemperature:
-40°C ~ 85°C (TA)
Features:
-
MountingType:
Surface Mount

TCA9517DR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including TCA9517DR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for TCA9517DR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

TCA9517DR information

Views：

TCA9517DR Typical application Circuitry

TCA9517DR

The TCA9517DR is a level-translating I²C and SMBus repeater designed by Texas Instruments. This integrated circuit (IC) serves as a bidirectional buffer for I²C and SMBus systems, facilitating communication between devices that operate at different voltage levels. Here's a detailed description of the TCA9517DR:

1. I²C and SMBus Repeater: The TCA9517DR is specifically designed to act as a repeater for I²C or SMBus data (SDA) and clock (SCL) lines, providing level translation and enhancing signal integrity across the bus.

2. Level Translation: This IC translates signals between two voltage domains. It supports voltage translation between a VCCA side (1.65 V to 3.6 V) and a VCCB side (2.3 V to 5.5 V), enabling seamless communication between devices with different supply voltages.

3. Bidirectional Buffering: The TCA9517DR provides bidirectional buffering for both data and clock lines, ensuring proper signal integrity, especially in long-distance or high-capacitance bus lines.

4. Hot Insertion: The IC supports hot insertion, allowing components to be added or removed from the bus while the system is powered upwithout causing data corruption or glitches.

5. Pre-Charged Bus: The repeater pre-charges the bus capacitance of the SDA and SCL lines using pull-upresistors to prevent glitches on the bus during hot insertion.

6. High-Impedance SDA, SCL Pins: When the IC is unpowered, the SDA and SCL pins maintain a high-impedance state, ensuring that the TCA9517DR does not load the bus.

7. Enable Pin (EN): The TCA9517DR features an enable pin that can be used to activate or deactivate the device. When disabled, the repeater enters a low-power standby mode and the I/O pins are isolated.

8. Package: The TCA9517DR is typically available in an SOIC (Small Outline Integrated Circuit) package, which is suitable for a variety of applications.

9. Applications: The IC is ideal for applications requiring I²C or SMBus communication between devices with different supply voltages, such as multi-voltage systems, industrial equipment, embedded systems, and consumer electronics.

10. Datasheet: For detailed specifications, pin configurations, electrical characteristics, and application notes, it is recommended to consult the datasheet of the TCA9517DR, which can be obtained from Texas Instruments' website or from authorized distributors.

In summary, the TCA9517DR is a level-translating I²C and SMBus repeater that offers bidirectional buffering, signal integrity enhancement, and voltage level translation, making it a valuable component in systems that require robust communication between devices operating at different voltages.
