STMicroelectronics STM8L151R8T6

Part No.:: STM8L151R8T6

Manufacturer:: STMicroelectronics

Package:: 64-LQFP

Datasheet:: STM8L151R8T6.pdf

Description:: IC MCU 8BIT 64KB FLASH 64LQFP

In Stock:: 3462

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM8L151R8T6 Specifications

Package/Case:
64-LQFP
Packaging:
Tray
Series:
STM8L EnergyLite
RoHS:
RoHS
Speed:
16MHz
RAM Size:
4K x 8
Core Size:
8-Bit
EEPROM Size:
2K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, IR, POR, PWM, WDT
Connectivity:
I²C, IrDA, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
54
Core Processor:
STM8
Data Converters:
A/D 28x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
