STMicroelectronics STM8AF6266TDX

Part No.:: STM8AF6266TDX

Manufacturer:: STMicroelectronics

Package:: 32-LQFP

Datasheet:: STM8AF6266TDX.pdf

Description:: IC MCU 8BIT 32KB FLASH 32LQFP

In Stock:: 3191

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM8AF6266TDX Specifications

Package/Case:
32-LQFP
Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100, STM8A
RoHS:
RoHS
Speed:
16MHz
RAM Size:
2K x 8
Core Size:
8-Bit
EEPROM Size:
1K x 8
Part Status:
Not For New Designs
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
25
Core Processor:
STM8A
Data Converters:
A/D 7x10b
Oscillator Type:
Internal
Program Memory Size:
32KB (32K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 150°C (TA)
