STMicroelectronics STM8AF52A9TAY

Part No.:: STM8AF52A9TAY

Manufacturer:: STMicroelectronics

Package:: 64-LQFP

Datasheet:: STM8AF52A9TAY.pdf

Description:: IC MCU 8BIT 128KB FLASH 64LQFP

In Stock:: 2130

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM8AF52A9TAY Specifications

Package/Case:
64-LQFP
Packaging:
Tray
Series:
STM8A
RoHS:
RoHS
Speed:
24MHz
RAM Size:
6K x 8
Core Size:
8-Bit
EEPROM Size:
2K x 8
Part Status:
Not For New Designs
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
CANbus, I²C, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
52
Core Processor:
STM8A
Data Converters:
A/D 16x10b
Oscillator Type:
Internal
Program Memory Size:
128KB (128K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

STM8AF52A9TAY this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including STM8AF52A9TAY price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for STM8AF52A9TAY to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

STM8AF52A9TAY information

Views：

STM8AF52A9TAY Typical application Circuitry

STM8AF52A9TAY

STM8AF52A9TAY is part of the STM8AF series of microcontrollers, which are tailored for automotive applications, providing robust features suitable for environments that demand high reliability and advanced functionalities. This particular model is known for its enhanced I/O capabilities and extensive memory, making it well-suited for complex automotive control systems such as body control modules and gateways. Here's how to effectively set up and connect the STM8AF52A9TAY:

1. Power Supply Connections:

To power the STM8AF52A9TAY, connect the VDD pin to a stable and regulated power supply, typically requiring 5V, which is standard in automotive applications. Additionally, the VSS pin must be connected to ground. This setup is crucial for maintaining stable operations and minimizing the potential for noise, which is particularly important in the noisy electrical environments found in vehicles.

2. External Oscillator Configuration:

Attach a crystal oscillator to the OSCIN and OSCOUT pins to provide a precise clock source. This is essential for applications that require accurate timing for tasks such as sensor data processing and real-time control of actuators.

3. GPIO Configuration:

The GPIO pins on the STM8AF52A9TAY, such as PD0 or PD1, should be configured according to the specific needs of your application. These pins can be used as digital inputs or outputs to control various automotive peripherals, such as lighting systems, motor controllers, and other sensors.

4. CAN Interface:

For communication within the automotive network, the STM8AF52A9TAY features a CAN interface, which should be connected to a CAN transceiver. This connection is vital for enabling robust and reliable communication with other components in the vehicle's CAN network, facilitating data exchange and system coordination.

5. USART Communication:

Set up USART communication by connecting the USART TX and RX pins (for example, Pin 25 for TX and Pin 26 for RX). These connections are important for data communication with diagnostic tools, other controllers, or during system development and debugging.

By adhering to these setup instructions, you can effectively integrate the STM8AF52A9TAY into automotive applications, leveraging its high performance and extensive feature set to achieve reliable and efficient system operations.
