STMicroelectronics STM32L100C6U6ATR

Part No.:: STM32L100C6U6ATR

Manufacturer:: STMicroelectronics

Package:: 48-UFQFN Exposed Pad

Datasheet:: STM32L100C6U6ATR.pdf

Description:: IC MCU 32BIT 32KB FLASH 48UFQFPN

In Stock:: 3642

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32L100C6U6ATR Specifications

Package/Case:
48-UFQFN Exposed Pad
Packaging:
Tape & Reel (TR)
Series:
STM32L1
RoHS:
RoHS
Speed:
32MHz
RAM Size:
4K x 8
Core Size:
32-Bit
EEPROM Size:
2K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
37
Core Processor:
ARM® Cortex®-M3
Data Converters:
A/D 16x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
32KB (32K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
