STMicroelectronics STM32H747BIT6

Part No.:: STM32H747BIT6

Manufacturer:: STMicroelectronics

Package:: 208-LQFP

Datasheet:: STM32H747BIT6.pdf

Description:: IC MCU 32BIT 2MB FLASH 208LQFP

In Stock:: 3720

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32H747BIT6 Specifications

Package/Case:
208-LQFP
Packaging:
Tray
Series:
STM32H7
RoHS:
RoHS
Speed:
240MHz, 480MHz
RAM Size:
1M x 8
Core Size:
32-Bit Dual-Core
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
168
Core Processor:
ARM® Cortex®-M4, Cortex®-M7
Data Converters:
A/D 32x16b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
2MB (2M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
