STMicroelectronics STM32F765VIH6

Part No.:: STM32F765VIH6

Manufacturer:: STMicroelectronics

Package:: 100-TFBGA

Datasheet:: STM32F765VIH6.pdf

Description:: IC MCU 32BIT 2MB FLASH 100TFBGA

In Stock:: 2263

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F765VIH6 Specifications

Package/Case:
100-TFBGA
Packaging:
Tray
Series:
STM32F7
RoHS:
RoHS
Speed:
216MHz
RAM Size:
512K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
82
Core Processor:
ARM® Cortex®-M7
Data Converters:
A/D 16x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
2MB (2M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

STM32F765VIH6 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including STM32F765VIH6 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for STM32F765VIH6 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

STM32F765VIH6 information

Views：

STM32F765VIH6 Typical application Circuitry Schematics

Another microcontroller model in the STM32F7 series, which is based on the same ARM Cortex-M7 architecture, is the STM32F765VIH6. Creating an application circuit for STM32F765VIH6 involves various aspects that are crucial for its reliable functionality. A Basic Application Circuit May Involve:

1. Power Supply: - VDD: Connect to a regulated power supply, typically 3.3V. - VSS: All ground pins should be connected to the common ground. - VCAP: To stabilize the internal voltage regulator, connect capacitors in the manner described in the datasheet. - AVDD, AVSS: Connect analog power and ground if analog peripherals are in use.

2. Clock Circuit: - Connect a crystal or ceramic resonator between the PH0 and PH1 pins to provide an external clock. - Connect capacitors (typically 20 pF) from each of these pins to ground.

3. Reset Circuit: - NRST: Connect a pull-up resistor (10kΩ typically) to VDD and optionally a push-button to ground for manual reset.

4. Programming and Debugging Interface: - For SWD: Connect PA13 to SWDIO and PA14 to SWCLK of the debugger. - For JTAG debugging: Connect JTAG pins (PA15, PA13, PA14, and PB3) to the debugger.

5. Boot Mode Pins: - BOOT0 and BOOT1: Configure according to your boot mode (from flash, system memory, or SRAM).

6. GPIO: - Make sure to follow I/O pin considerations, such as avoiding overvoltage and respecting source/sink current limitations.

7. USB Interface (If Used): - DP and DM: Connect to a USB connector through 22Ω resistors. - Optionally include ESD protection diodes on USB data lines.

8. Analog Setup (If Used): - VREF+: Connect, if desired, to an outside reference voltage. - Ensure that the analog ground (AVSS) and power (AVDD) pins are connected and well-decoupled.

9. External Peripherals: - Connect LEDs, buttons, displays, communication modules, etc., as per your project requirements.

10. Decoupling and Filtering: - Place 100nF capacitors close to VDD pins and a few bulk capacitors (e.g., 10μF) across the board.

11. Optional External Oscillators: - If using RTC, connect a 32.768kHz crystal to PC14 and PC15 pins and capacitors as per the datasheet.

12. MCU Configuration and Bypass Capacitors: - Follow guidelines provided in the datasheet for capacitor placement and values for VDD and VCAP pins.

Additional Notes: - Schematic and PCB Design: - Employ a CAD tool for schematic capture and PCB layout (e.g., KiCad, Altium). - Firmware Development: - Use the STM32F765VIH6 or another suitable IDE for firmware development. - The STM32F765VIH6tool may be useful for creating initialization code and configuring peripherals. - Datasheet and Reference Manual: - Always refer to the STM32F765VIH6 datasheet and reference manual for detailed specifications and guidelines. Conclusion: Ensure your design complies with EMC and ESD guidelines, and follow best practices for PCB layout, especially when dealing with high-speed signals (USB, Ethernet, etc.), analog signals, or RF modules. Testing and validation are also vital to ensure the robustness of the final product. Always revise your designs against the datasheet and reference manual, as well as any errata that may be applicable to ensure optimal performance and reliability.
