STMicroelectronics STM32F446ZEJ6

Part No.:: STM32F446ZEJ6

Manufacturer:: STMicroelectronics

Package:: 144-UFBGA

Datasheet:: STM32F446ZEJ6.pdf

Description:: IC MCU 32BIT 512KB FLSH 144UFBGA

In Stock:: 2089

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F446ZEJ6 Specifications

Package/Case:
144-UFBGA
Packaging:
Tray
Series:
STM32F4
RoHS:
RoHS
Speed:
180MHz
RAM Size:
128K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, LVD, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, I²C, IrDA, LINbus, SAI, SD, SPDIF-Rx, SPI, UART/USART, USB, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
114
Core Processor:
ARM® Cortex®-M4
Data Converters:
A/D 24x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
512KB (512K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
