STMicroelectronics STM32F417IGH6

Part No.:: STM32F417IGH6

Manufacturer:: STMicroelectronics

Package:: 201-UFBGA

Datasheet:: STM32F417IGH6.pdf

Description:: IC MCU 32BIT 1MB FLASH 176UFBGA

In Stock:: 2701

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F417IGH6 Specifications

Package/Case:
201-UFBGA
Packaging:
Tray
Series:
STM32F4
RoHS:
RoHS
Speed:
168MHz
RAM Size:
192K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Connectivity:
CANbus, DCMI, EBI/EMI, Ethernet, I²C, IrDA, LINbus, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
140
Core Processor:
ARM® Cortex®-M4
Data Converters:
A/D 24x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
1MB (1M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
