STMicroelectronics STM32F417IEH6

Part No.:: STM32F417IEH6

Manufacturer:: STMicroelectronics

Package:: 201-UFBGA

Datasheet:: STM32F417IEH6.pdf

Description:: IC MCU 32BIT 512KB FLSH 176UFBGA

In Stock:: 2721

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F417IEH6 Specifications

Package/Case:
201-UFBGA
Packaging:
Tray
Series:
STM32F4
RoHS:
RoHS
Speed:
168MHz
RAM Size:
192K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Connectivity:
CANbus, DCMI, EBI/EMI, Ethernet, I²C, IrDA, LINbus, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
140
Core Processor:
ARM® Cortex®-M4
Data Converters:
A/D 24x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
512KB (512K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

STM32F417IEH6 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including STM32F417IEH6 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for STM32F417IEH6 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

STM32F417IEH6 information

Views：

STM32F417IEH6 Typical application Circuitry

STM32F417IEH6 is a microcontroller developed by STMicroelectronics, belonging to their STM32F4 series of high-performance microcontrollers based on the ARM Cortex-M4F with FPU core.

Core Features

The STM32F417IEH6 microcontroller comes with a range of essential features:

- A 32-bit ARM Cortex-M4F core running at a maximum frequency of 168 MHz.

- A total of 2 MB of Flash memory and 192+4 KB of SRAM.

- A host of embedded peripherals including twelve 16-bit timers, two 12-bit ADCs, two DACs, USB OTG, Ethernet, and up to 15 communication interfaces.

- Cryptographic acceleration, hash, and random number generation.

Applications

The power and flexibility of the STM32F417IEH6 allow it to be employed in a wide variety of application scenarios, ranging from real-time systems and IoT devices to more complex scenarios like machine learning and computer vision.

Let's consider a real-world application scenario where STM32F417IEH6 is used as a main controller for a sensor node in an IoT system.

Circuit Implementation

Assuming we're creating a sensor node that includes a temperature sensor (DS18B20) and an RF transceiver for wireless communication (nRF24L01), here's how we might connect these components to the STM32F417IEH6:

1. Power Pins: Connect the VDD pins (Pin 2, Pin 63) to a 3.3V power supply, and ground the VSS pins (Pin 1, Pin 64).

2. Clock Source: Connect a 16 MHz crystal oscillator to PH0 and PH1 (Pin 26 and Pin 27) to provide the clock signal for the microcontroller.

3. DS18B20 Temperature Sensor: Connect the data line of the DS18B20 to PA0 (Pin 41) on the STM32F417IEH6.

4. nRF24L01 RF Transceiver: Connect the SPI lines (SCK, MISO, MOSI) from the nRF24L01 to the SPI1 peripheral on the STM32F417IEH6 (PA5, PA6, PA7 - Pins 47, 48, 49, respectively). Connect the Chip Enable (CE) and Chip Select Not (CSN) lines to PC0 and PC1 (Pins 32, 33) respectively.

Design Considerations

Designing a circuit with STM32F417IEH6, some points should be considered:

- Power Supply: Ensure a clean, stable 3.3V power supply. Decoupling capacitors should be placed near the VDD and VSS pins to filter out any high-frequency noise.

- Firmware: Use ST's provided libraries and drivers to get the most out of the MCU's capabilities.

- PCB Design: It's crucial to follow good practices for PCB layout, such as minimizing trace lengths and avoiding sharp corners, to prevent signal integrity issues, especially when using high-speed peripherals.

- Thermal Management: If the microcontroller is expected to perform heavy computational tasks, consider including heat dissipation mechanisms in the design.

The STM32F417IEH6 microcontroller is a versatile and powerful choice for an array of applications, with its high clock frequency, substantial memory, and diverse peripherals.
