STMicroelectronics STM32F407ZGT7

Part No.:: STM32F407ZGT7

Manufacturer:: STMicroelectronics

Package:: 144-LQFP

Datasheet:: STM32F407ZGT7.pdf

Description:: IC MCU 32BIT 1MB FLASH 144LQFP

In Stock:: 3473

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F407ZGT7 Specifications

Package/Case:
144-LQFP
Packaging:
Tray
Series:
STM32F4
RoHS:
RoHS
Speed:
168MHz
RAM Size:
192K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Connectivity:
CANbus, DCMI, EBI/EMI, Ethernet, I²C, IrDA, LINbus, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
114
Core Processor:
ARM® Cortex®-M4
Data Converters:
A/D 24x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
1MB (1M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)

STM32F407ZGT7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including STM32F407ZGT7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for STM32F407ZGT7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

STM32F407ZGT7 information

Views：

STM32F407ZGT7 Typical application Circuitry

The STM32F407ZGT7 is a versatile, high-performance microcontroller chip that is part of STMicroelectronics' STM32F4 series. It is based on the 32-bit RISC ARM® Cortex®-M4 CPU and has a maximum operating frequency of 168 MHz.

Important Characteristics

There are several remarkable attributes of the STM32F407ZGT7:

- It has an ARM® Cortex®-M4 32-bit RISC processor that runs at up to 168 MHz, making it a high-performance device.

- The microcontroller integrates a Floating-Point Unit (FPU) for supporting single-precision operations.

- It possesses a rich memory configuration with 1 MB of Flash and 192+4 KB of SRAM.

- It incorporates an array of communication interfaces, including I2C, SPI, USART, and USB 2.0 full-speed.

- Furthermore, the STM32F407ZGT7 encompasses advanced peripherals like 3×12-bit, 2.4 MSPS ADCs and 2×12-bit D/A converters.

- Additionally, it includes an RTC and backup registers.

- Thanks to these advanced features, the microcontroller is suitable for intricate applications such as motor control, power conversion, and real-time tracking.

Application Scenarios

The STM32F407ZGT7 is a multipurpose chip and finds extensive application in numerous fields, from complex motor control systems to power management systems, real-time tracking systems, and sensor hubs. We'll use its application in a fundamental IoT-based home automation system as an example.

Circuit Description

Let's design a basic IoT-based home automation system using the STM32F407ZGT7 and ESP8266 WiFi module.

Power Connection: First, provide the 3.3V power supply to the VDD pins (Pins 13, 23) of the STM32F407ZGT7, and connect VSS pins (Pins 12, 22) to the ground. Near these pins, a 100nF decoupling capacitor ought to be installed.

Clock Configuration: An 8 MHz crystal oscillator is connected between the PC14/OSC32_IN and PC15/OSC32_OUT pins (Pins 8, 9) for reliable system clock generation.

ESP8266 WiFi Module: This module is connected to USART3 (PB10/PB11) of the STM32F407ZGT7 for WiFi connectivity.

Relay Module Interface: Connect a relay module to control appliances. Connect relay module's control pin to PA0 (Pin 18) of the STM32F407ZGT7.

Considerations in Design

Designing a circuit with STM32F407ZGT7 necessitates several considerations:

Consistent Power Supply: The stability of the power supply is critical. Decoupling capacitors should be put close to the power supply pins.

Accurate Timing: An external crystal oscillator should be utilized for precise system timing.

Circuit Protection: Include appropriate protection measures like ESD and EMC protection in the circuit design.

Thermal Management: Keep in mind the thermal aspects, as the STM32F407ZGT7 can generate heat during high-speed operations.

In conclusion, the STM32F407ZGT7 is a robust and flexible microcontroller suitable for a wide array of applications due to its advanced features and high performance.
