STMicroelectronics STM32F407IEH6

Part No.:: STM32F407IEH6

Manufacturer:: STMicroelectronics

Package:: 201-UFBGA

Datasheet:: STM32F407IEH6.pdf

Description:: IC MCU 32BIT 512KB FLSH 176UFBGA

In Stock:: 3914

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F407IEH6 Specifications

Package/Case:
201-UFBGA
Packaging:
Tray
Series:
STM32F4
RoHS:
RoHS
Speed:
168MHz
RAM Size:
192K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Connectivity:
CANbus, DCMI, EBI/EMI, Ethernet, I²C, IrDA, LINbus, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
140
Core Processor:
ARM® Cortex®-M4
Data Converters:
A/D 24x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
512KB (512K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

STM32F407IEH6 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including STM32F407IEH6 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for STM32F407IEH6 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

STM32F407IEH6 information

Views：

STM32F407IEH6 Typical application Circuitry

STM32F407IEH6

The STM32F407IEH6, developed by Microelectronics, is a high-performance foundation line, ARM Cortex-M4 32-bit microcontroller packed with a comprehensive set of features. It's key to understand its detailed pin connection strategy for effectively utilizing the microcontroller.

1. Power Supply Connections: The STM32F407IEH6 operates at a core supply voltage (VDD) of 2.3V to 3.6V. Connect the supply voltage to the VDD pins (pins 28, 48, 67) and ground (VSS) to the GND pins (pins 27, 47, 66). To enhance performance and stability, decoupling capacitors are recommended near the VDD and GND pins.

2. Programming and Debugging Interface: The STM32F407IEH6 leverages the JTAG/SWD interface for programming and debugging. Connect the TMS/SDIO (pin 7), TCK/WALK (pin 6), TDI (pin 5), TO/TRACES (pin 4), and NRST (pin 10) pins to your JTAG/SWD debugger.

3. Digital I/O and Peripheral Interfacing: The microcontroller offers various GPO pins dispersed across several ports (PA, PB, PC, PD, PE, PF, and PG). For instance, to interface with an LED, connect the anode to a GPO (like PA0 on pin 23) and the cathode to ground. Interfaces like SPI, I2C, PART, and CAN can be connected to corresponding pins as specified in the data sheet.

4. Analog Input Connections: The STM32F407IEH6 features multiple ADC channels. To interface an analog sensor, utilize an ADC input pin like PA0 (pin 23).

5. Clock Source Connections: If an external clock source is preferred, connect it to the OSC_IN pin (pin 8), and for an external crystal instead, connect it between the OSC_IN and OSC_OUT pins (pins 8 and 9 respectively).

In conclusion, it's critical when designing a circuit with the STM32F407IEH6 to understand your application's needs and the corresponding microcontroller pins that can fulfill them. Always refer to the data sheet and reference manual of the STM32F407IEH6 for accurate pin functionalities and their electrical characteristics.
