STMicroelectronics STM32F405VGT7TR

Part No.:: STM32F405VGT7TR

Manufacturer:: STMicroelectronics

Package:: 100-LQFP

Datasheet:: STM32F405VGT7TR.pdf

Description:: IC MCU 32BIT 1MB FLASH 100LQFP

In Stock:: 2315

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F405VGT7TR Specifications

Package/Case:
100-LQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
STM32F4
RoHS:
RoHS
Speed:
168MHz
RAM Size:
192K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, I²C, IrDA, LINbus, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
82
Core Processor:
ARM® Cortex®-M4
Data Converters:
A/D 16x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
1MB (1M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
