STMicroelectronics STM32F334C8T7

Part No.:: STM32F334C8T7

Manufacturer:: STMicroelectronics

Package:: 48-LQFP

Datasheet:: STM32F334C8T7.pdf

Description:: IC MCU 32BIT 64KB FLASH 48LQFP

In Stock:: 3561

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F334C8T7 Specifications

Package/Case:
48-LQFP
Packaging:
Tray
Series:
STM32F3
RoHS:
RoHS
Speed:
72MHz
RAM Size:
12K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, I²C, IrDA, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
37
Core Processor:
ARM® Cortex®-M4
Data Converters:
A/D 15x12b; D/A 3x12b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
