STMicroelectronics STM32F107VCH6

Part No.:: STM32F107VCH6

Manufacturer:: STMicroelectronics

Package:: 100-LFBGA

Datasheet:: STM32F107VCH6.pdf

Description:: IC MCU 32BIT 256KB FLSH 100LFBGA

In Stock:: 2632

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F107VCH6 Specifications

Package/Case:
100-LFBGA
Packaging:
Tray
Series:
STM32F1
RoHS:
RoHS
Speed:
72MHz
RAM Size:
64K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, Voltage Detect, WDT
Connectivity:
CANbus, Ethernet, I²C, IrDA, LINbus, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
80
Core Processor:
ARM® Cortex®-M3
Data Converters:
A/D 16x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

STM32F107VCH6 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including STM32F107VCH6 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for STM32F107VCH6 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
