Name: STM32F103TBU7
Brand: STMicroelectronics
SKU: STM32F103TBU7
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

STMicroelectronics STM32F103TBU7

Part No.:: STM32F103TBU7

Manufacturer:: STMicroelectronics

Package:: 36-VFQFN Exposed Pad

Datasheet:: STM32F103TBU7.pdf

Description:: IC MCU 32BIT 128KB FLSH 36VFQFPN

In Stock:: 3722

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F103TBU7 Specifications

Package/Case:
36-VFQFN Exposed Pad
Packaging:
Tray
Series:
STM32F1
RoHS:
RoHS
Speed:
72MHz
RAM Size:
20K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT
Connectivity:
CANbus, I²C, IrDA, LINbus, SPI, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
26
Core Processor:
ARM® Cortex®-M3
Data Converters:
A/D 10x12b
Oscillator Type:
Internal
Program Memory Size:
128KB (128K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
