STMicroelectronics STM32F103T6U6A

Part No.:: STM32F103T6U6A

Manufacturer:: STMicroelectronics

Package:: 36-VFQFN Exposed Pad

Datasheet:: STM32F103T6U6A.pdf

Description:: IC MCU 32BIT 32KB FLASH 36VFQFPN

In Stock:: 2632

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F103T6U6A Specifications

Package/Case:
36-VFQFN Exposed Pad
Packaging:
Tray
Series:
STM32F1
RoHS:
RoHS
Speed:
72MHz
RAM Size:
10K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT
Connectivity:
CANbus, I²C, IrDA, LINbus, SPI, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
26
Core Processor:
ARM® Cortex®-M3
Data Converters:
A/D 10x12b
Oscillator Type:
Internal
Program Memory Size:
32KB (32K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

STM32F103T6U6A this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including STM32F103T6U6A price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for STM32F103T6U6A to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

STM32F103T6U6A information

Views：

STM32F103T6U6A Typical application Circuitry

STM32F103T6U6A

STM32F103T6U6A is a potent microcontroller embedded within the STM32F103 series from STMicroelectronics, leveraging the ARM Cortex-M3 processor for high-efficiency computational tasks. The STM32F103T6U6A, which is well-known for its small UFQFPN28 packaging, is a flexible option for a variety of applications, such as industrial controls, automotive systems, and consumer electronics. This detailed guide focuses on critical connection methodologies specific to the STM32F103T6U6A, illustrating each step down to individual pin connections:

1. Proper Power Configuration:

- The power supply should be connected to the VDD pin (Pin 9) of the STM32F103T6U6A to ensure a consistent 3.3V input. Concurrently, connect the ground to the VSS pin (Pin 8). Maintaining correct power levels is crucial for the STM32F103T6U6A's stability and performance.

2. External Clock Setup:

- An external clock source, typically a crystal oscillator, should be connected across OSC_IN (Pin 5) and OSC_OUT (Pin 6). This ensures that the STM32F103T6U6A receives a stable and accurate clock signal for all operations.

3. Reset Pin Arrangement:

- To facilitate manual resetting capabilities, configure a push-button switch connected to the NRST pin (Pin 7). This setup should include a pull-up resistor (recommended value 10 kΩ) linking NRST to the power supply, keeping the pin normally high and enabling reset when pressed.

4. USART Configuration for Communication:

- For essential serial communication, align the USART1_TX (Pin 22) and USART1_RX (Pin 21) pins for data transmission and reception, respectively. These connections are vital for the STM32F103T6U6A to interact with other digital systems or interfaces.

5. Debug Interface Connection:

- Connect the SWDIO (Pin 27) and SWCLK (Pin 28) to a suitable debugger, like the ST-Link, to enable straightforward programming and real-time debugging of the STM32F103T6U6A.

6. GPIO Utilization for Peripheral Integration:

- Leverage the General-Purpose Input/Output (GPIO) capabilities by connecting devices such as LEDs to GPIO pins (e.g., PA0 on Pin 10). This connection can serve as an output to visually represent the device's state, useful in both testing and operational phases.

Following these enumerated steps allows for the comprehensive integration of the STM32F103T6U6A into diverse electronic applications. Each connection point has been clearly outlined to ensure that all functionalities of the STM32F103T6U6A are accessible and fully operational in any system configuration. This precise approach to circuit connection not only optimizes the performance of the STM32F103T6U6A but also enhances the reliability of the overall system.
