STMicroelectronics STM32F103T4U6A

Part No.:: STM32F103T4U6A

Manufacturer:: STMicroelectronics

Package:: 36-VFQFN Exposed Pad

Datasheet:: STM32F103T4U6A.pdf

Description:: IC MCU 32BIT 16KB FLASH 36VFQFPN

In Stock:: 3042

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F103T4U6A Specifications

Package/Case:
36-VFQFN Exposed Pad
Packaging:
Tray
Series:
STM32F1
RoHS:
RoHS
Speed:
72MHz
RAM Size:
6K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT
Connectivity:
CANbus, I²C, IrDA, LINbus, SPI, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
26
Core Processor:
ARM® Cortex®-M3
Data Converters:
A/D 10x12b
Oscillator Type:
Internal
Program Memory Size:
16KB (16K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

STM32F103T4U6A this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including STM32F103T4U6A price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for STM32F103T4U6A to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

STM32F103T4U6A information

Views：

STM32F103T4U6A Typical application Circuitry

STM32F103T4U6A

STM32F103T4U6A is an advanced microcontroller embedded within the extensive STM32F1 series produced by STMicroelectronics, renowned for incorporating the high-efficiency ARM Cortex-M3 processor. This model boasts a unique blend of performance, providing robust capabilities in a compact UFQFPN36 package, making it a prime choice for space-sensitive applications in automation, control systems, and consumer electronics. In this guide, we detail the method to accurately wire the STM32F103T4U6A within a circuit, specifying connections right down to individual pins:

1. Supply Voltage and Grounding Details:

- To power the STM32F103T4U6A, connect the power supply to the VDD pin (Pin 4) ensuring a steady 3.3V input. Simultaneously, attach the ground line to the VSS pin (Pin 3). Proper voltage levels must be maintained to prevent any operational issues or damage to the STM32F103T4U6A.

2. Clock Source Arrangement:

- For the microcontroller's clock, a quartz crystal oscillator is typically utilized, linked between the OSC_IN (Pin 5) and OSC_OUT (Pin 6). This connection is crucial for the STM32F103T4U6A as it ensures reliable and stable clock signals for all processing tasks.

3. Reset Pin Setup:

- A functional reset circuit is vital for regular operation and troubleshooting. Integrate a push-button to the NRST pin (Pin 7), which allows manual resetting of the STM32F103T4U6A. Additionally, a pull-up resistor (around 10 kΩ) should connect this pin to the power supply to default the pin to a high state.

4. Serial Communication Interface:

- Utilize USART1 for serial communication, which involves connecting USART1_TX (Pin 30) and USART1_RX (Pin 31) for transmitting and receiving data, respectively. These pins enable the STM32F103T4U6A to communicate effectively with other digital devices or debugging tools.

5. Programming and Debugging Connections:

- To program and debug the STM32F103T4U6A, connect the SWDIO (Pin 34) and SWCLK (Pin 35) to a compatible ST-Link debugger. These connections are indispensable for loading software onto the STM32F103T4U6A and for performing real-time diagnostic checks.

6. Peripheral Device Configuration:

- Configure additional functionalities by connecting various peripheral devices to the GPIO pins. For example, set up an LED indicator by connecting an LED through a resistor to PA0 (Pin 10), which serves as a simple output to monitor the operational state of the STM32F103T4U6A.

By adhering to these meticulous instructions for pin connections, developers can ensure that the STM32F103T4U6A is perfectly configured for optimal performance in their specific application needs. Each connection point has been precisely defined to facilitate the effective integration of the STM32F103T4U6A into diverse electronic systems.
