STMicroelectronics STM32F100VET6BTR

Part No.:: STM32F100VET6BTR

Manufacturer:: STMicroelectronics

Package:: 100-LQFP

Datasheet:: STM32F100VET6BTR.pdf

Description:: IC MCU 32BIT 512KB FLASH 100LQFP

In Stock:: 3202

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

STM32F100VET6BTR Specifications

Package/Case:
100-LQFP
Packaging:
Tape & Reel (TR)
Series:
STM32F1
RoHS:
RoHS
Speed:
24MHz
RAM Size:
32K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, PDR, POR, PVD, PWM, Temp Sensor, WDT
Connectivity:
I²C, IrDA, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
80
Core Processor:
ARM® Cortex®-M3
Data Converters:
A/D 16x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
512KB (512K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
