STMicroelectronics ST72F325K6T3

Part No.:: ST72F325K6T3

Manufacturer:: STMicroelectronics

Package:: 32-LQFP

Datasheet:: ST72F325K6T3.pdf

Description:: IC MCU 8BIT 32KB FLASH 32LQFP

In Stock:: 3239

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ST72F325K6T3 Specifications

Package/Case:
32-LQFP
Packaging:
Tray
Series:
ST7
RoHS:
RoHS
Speed:
8MHz
RAM Size:
1K x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Not For New Designs
Peripherals:
LVD, POR, PWM, WDT
Connectivity:
I²C, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
24
Core Processor:
ST7
Data Converters:
A/D 6x10b
Oscillator Type:
Internal
Program Memory Size:
32KB (32K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
