Microchip Technology SST25VF032B-80-4I-S2AF-T

Part No.:: SST25VF032B-80-4I-S2AF-T

Manufacturer:: Microchip Technology

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: SST25VF032B-80-4I-S2AF-T.pdf

Description:: IC FLASH 32MBIT SPI 80MHZ 8SOIC

In Stock:: 3698

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SST25VF032B-80-4I-S2AF-T Specifications

Package/Case:
8-SOIC (0.209, 5.30mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SST25
ProductStatus:
Obsolete
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH
MemorySize:
32Mb (4M x 8)
MemoryInterface:
SPI
ClockFrequency:
80 MHz
WriteCycleTime-WordPage:
10µs
AccessTime:
-
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
