NXP USA Inc. SPC5746RK1MMT5

Part No.:: SPC5746RK1MMT5

Manufacturer:: NXP USA Inc.

Package:: 252-LFBGA

Datasheet:: SPC5746RK1MMT5.pdf

Description:: IC MCU 32BIT 4MB FLASH 252MAPBGA

In Stock:: 2524

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SPC5746RK1MMT5 Specifications

Package/Case:
252-LFBGA
Packaging:
Tray
Series:
Automotive, AEC-Q100 MPC57xx
RoHS:
RoHS
Speed:
200MHz
RAM Size:
256K x 8
Core Size:
32-Bit Tri-Core
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, LVD, POR, Zipwire
Connectivity:
CANbus, Ethernet, I²C, LINbus, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
-
Core Processor:
e200z4
Data Converters:
A/D 12b SAR, 16b Sigma-Delta
Oscillator Type:
Internal
Program Memory Size:
4MB (4M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
