NXP USA Inc. SPC5643LAMLQ1

Part No.:: SPC5643LAMLQ1

Manufacturer:: NXP USA Inc.

Package:: 144-LQFP

Datasheet:

Description:: IC MCU 32BIT 1MB FLASH 144LQFP

In Stock:: 2152

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SPC5643LAMLQ1 Specifications

Package/Case:
144-LQFP
Packaging:
Tray
Series:
MPC56xx Qorivva
RoHS:
RoHS
Speed:
120MHz
RAM Size:
128K x 8
Core Size:
32-Bit Dual-Core
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, FlexRay, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
-
Core Processor:
e200z4
Data Converters:
A/D 32x12b
Oscillator Type:
Internal
Program Memory Size:
1MB (1M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
