NXP USA Inc. SPC5642AF2MLU1

Part No.:: SPC5642AF2MLU1

Manufacturer:: NXP USA Inc.

Package:: 176-LQFP

Datasheet:: SPC5642AF2MLU1.pdf

Description:: IC MCU 32BIT 2MB FLASH 176LQFP

In Stock:: 3498

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SPC5642AF2MLU1 Specifications

Package/Case:
176-LQFP
Packaging:
Tray
Series:
MPC56xx Qorivva
RoHS:
RoHS
Speed:
150MHz
RAM Size:
128K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, LINbus, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
84
Core Processor:
e200z4
Data Converters:
A/D 40x12b
Oscillator Type:
Internal
Program Memory Size:
2MB (2M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
