STMicroelectronics SPC563M64L5COAR

Part No.:: SPC563M64L5COAR

Manufacturer:: STMicroelectronics

Package:: 144-LQFP

Datasheet:: SPC563M64L5COAR.pdf

Description:: IC MCU 32BIT 1.5MB FLASH 144LQFP

In Stock:: 2694

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SPC563M64L5COAR Specifications

Package/Case:
144-LQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100, SPC56
RoHS:
RoHS
Speed:
80MHz
RAM Size:
94K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, LINbus, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
80
Core Processor:
e200z3
Data Converters:
A/D 32x12b
Oscillator Type:
Internal
Program Memory Size:
1.5MB (1.5M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)

SPC563M64L5COAR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SPC563M64L5COAR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SPC563M64L5COAR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
