STMicroelectronics SPC560D40L1B3E0X

Part No.:: SPC560D40L1B3E0X

Manufacturer:: STMicroelectronics

Package:: 64-LQFP

Datasheet:: SPC560D40L1B3E0X.pdf

Description:: IC MCU 32BIT 256KB FLASH 64LQFP

In Stock:: 3805

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SPC560D40L1B3E0X Specifications

Package/Case:
64-LQFP
Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100, SPC56
RoHS:
RoHS
Speed:
32MHz
RAM Size:
16K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, LVD, POR, PWM, WDT
Connectivity:
CANbus, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
45
Core Processor:
e200z0h
Data Converters:
A/D 16x12b
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
