STMicroelectronics SPC560B50L5C6E0Y

Part No.:: SPC560B50L5C6E0Y

Manufacturer:: STMicroelectronics

Package:: 144-LQFP

Datasheet:: SPC560B50L5C6E0Y.pdf

Description:: IC MCU 32BIT 512KB FLASH 144LQFP

In Stock:: 2889

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SPC560B50L5C6E0Y Specifications

Package/Case:
144-LQFP
Packaging:
Tray
Series:
Automotive, AEC-Q100, SPC56
RoHS:
RoHS
Speed:
64MHz
RAM Size:
32K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, I²C, LINbus, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
123
Core Processor:
e200z0h
Data Converters:
A/D 36x10b
Oscillator Type:
Internal
Program Memory Size:
512KB (512K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
