Name: SPC5566MVR132
Brand: NXP USA Inc.
SKU: SPC5566MVR132
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

NXP USA Inc. SPC5566MVR132

Part No.:: SPC5566MVR132

Manufacturer:: NXP USA Inc.

Package:: 416-BBGA

Datasheet:: SPC5566MVR132.pdf

Description:: IC MCU 32BIT 3MB FLASH 416PBGA

In Stock:: 2970

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SPC5566MVR132 Specifications

Package/Case:
416-BBGA
Packaging:
Tray
Series:
MPC55xx Qorivva
RoHS:
RoHS
Speed:
132MHz
RAM Size:
128K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
256
Core Processor:
e200z6
Data Converters:
A/D 40x12b
Oscillator Type:
External
Program Memory Size:
3MB (3M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
