Texas Instruments SN74LVC1T45DBVTG4

Part No.:: SN74LVC1T45DBVTG4

Manufacturer:: Texas Instruments

Package:: SOT-23-6

Datasheet:: SN74LVC1T45DBVTG4.pdf

Description:: IC TRNSLTR BIDIRECTIONAL SOT23-6

In Stock:: 2988

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74LVC1T45DBVTG4 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74LVC
ProductStatus:
Discontinued at Mosen
TranslatorType:
Voltage Level
ChannelType:
Bidirectional
NumberofCircuits:
1
ChannelsperCircuit:
1
Voltage-VCCA:
1.65 V ~ 5.5 V
Voltage-VCCB:
1.65 V ~ 5.5 V
InputSignal:
-
OutputSignal:
-
OutputType:
Tri-State, Non-Inverted
DataRate:
420Mbps
OperatingTemperature:
-40°C ~ 85°C (TA)
Features:
-
MountingType:
Surface Mount
