Texas Instruments SN74LVC1G11DCKRG4

Part No.:: SN74LVC1G11DCKRG4

Manufacturer:: Texas Instruments

Package:: SC-70-6

Datasheet:: SN74LVC1G11DCKRG4.pdf

Description:: IC GATE AND 1CH 3-INP SC70-6

In Stock:: 3146

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74LVC1G11DCKRG4 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74LVC
ProductStatus:
Discontinued at Mosen
LogicType:
AND Gate
NumberofCircuits:
1
NumberofInputs:
3
Features:
-
Voltage-Supply:
1.65V ~ 5.5V
Current-Quiescent(Max):
10 µA
Current-OutputHighLow:
32mA, 32mA
LogicLevel-Low:
0.7V ~ 0.8V
LogicLevel-High:
1.7V ~ 2V
MaxPropagationDelay@VMaxCL:
3.5ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

SN74LVC1G11DCKRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74LVC1G11DCKRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74LVC1G11DCKRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74LVC1G11DCKRG4 information

Views：

SN74LVC1G11DCKRG4 Typical application Circuitry

SN74LVC1G11DCKRG4

SN74LVC1G11DCKRG4 is a chip functioning as a single 3-input positive-AND gate, integral in digital electronics. It outputs a high signal only when all its three inputs are high, making it essential in various logic circuits and digital systems.

Application Scenario: Control Logic in Digital Systems

The SN74LVC1G11DCKRG4 is frequently used in control logic circuits within digital systems, such as microcontroller interfaces or signal routing systems.

Parameter Features

1. Voltage Flexibility: This chip operates over a wide range of voltages, typically 1.65V to 5.5V.

2. Low Power Consumption: Ideal for power-sensitive applications due to its minimal power requirement.

3. Fast Operation: Capable of high-speed operation, making it suitable for rapid digital processes.

Detailed Circuit Connection Description

1.Input Connection

- Pins 1, 2, and 3 (Inputs A, B, C): These pins are the inputs of the AND gate. Only when every one of these inputs is at a high level will the output be high.

2.Output Pin

- Pin 6 (Output Y): This pin provides the output of the AND operation.

3.Power Supply Consideration

- Pin 5 (Vcc): This pin should be connected to a positive power supply within the chip's operating voltage range.

4.Grounding

- Pin 4 (Ground): This pin needs to be properly grounded.

Design Considerations

1. Matching Input Levels: Ensure that the input levels to the SN74LVC1G11DCKRG4 match the logic levels for which the chip is designed.

2. Stable Power Supply: A stable power supply is crucial to maintain the chip's performance and reliability.

3. Decoupling Capacitors: To reduce noise and stabilize the voltage, use decoupling capacitors next to the power supply pin.

4. Ambient Conditions: Be mindful of the ambient conditions, such as temperature, that could affect the performance of the SN74LVC1G11DCKRG4.

In summary, when incorporating the SN74LVC1G11DCKRG4 in control logic circuits, attention to these design considerations is key to achieving a reliable and efficient operation.
