Texas Instruments SN74LVC1G11DCKR

Part No.:: SN74LVC1G11DCKR

Manufacturer:: Texas Instruments

Package:: SC-70-6

Datasheet:: SN74LVC1G11DCKR.pdf

Description:: IC GATE AND 1CH 3-INP SC70-6

In Stock:: 3353

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74LVC1G11DCKR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
74LVC
ProductStatus:
Active
LogicType:
AND Gate
NumberofCircuits:
1
NumberofInputs:
3
Features:
-
Voltage-Supply:
1.65V ~ 5.5V
Current-Quiescent(Max):
10 µA
Current-OutputHighLow:
32mA, 32mA
LogicLevel-Low:
0.7V ~ 0.8V
LogicLevel-High:
1.7V ~ 2V
MaxPropagationDelay@VMaxCL:
3.5ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

SN74LVC1G11DCKR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74LVC1G11DCKR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74LVC1G11DCKR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74LVC1G11DCKR information

Views：

SN74LVC1G11DCKR Typical application Circuitry

SN74LVC1G11DCKR

A common component in digital logic circuits is the single 3-input positive-AND gate chip, SN74LVC1G11DCKR. This chip is designed to perform the logical AND operation, where the output is high only if all the inputs are high.

Application Scenario: Logic Gate Circuit

In logic gate circuits, the SN74LVC1G11DCKR is often used to implement complex logic functions by combining multiple simple logic gates.

Parameter Features

1. Wide Voltage Range: It operates within a voltage range of 1.65V to 5.5V, accommodating various power supplies.

2. Low Power Consumption: Critical for battery-operated devices, it consumes minimal power.

3. High-Speed Operation: Suitable for high-speed digital circuits due to its fast switching capabilities.

Detailed Circuit Connection Description

Input Connections

- Pins 1, 2, and 3 (A, B, C): These are the input pins for the AND gate. Only when each of these inputs is high is the output high.

Output Connection

- Pin 6 (Y): This is the output pin. It outputs the result of the AND operation on the inputs.

Power Supply and Ground

- Pin 5 (Vcc): Connects to the positive power supply.

- Pin 4 (GND): Connects to the ground.

Design Considerations

1. Input Signal Levels: Ensure that the input signals to the SN74LVC1G11DCKR are within the valid range for high and low logic levels.

2. Noise Immunity: Design the circuit to minimize noise, especially on the input lines, to avoid false triggering.

3. Power Supply Decoupling: Use decoupling capacitors near the power supply pin to stabilize the supply voltage and reduce noise.

4. Operating Temperature Range: Consider the ambient temperature range in which the circuit will operate to ensure the SN74LVC1G11DCKR functions reliably.

Incorporating the SN74LVC1G11DCKR in logic gate circuits requires careful attention to these factors to ensure accurate and reliable logic operations.
