Texas Instruments SN74LV4052APWRG4

Part No.:: SN74LV4052APWRG4

Manufacturer:: Texas Instruments

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: SN74LV4052APWRG4.pdf

Description:: IC MULTIPLEXER DUAL 4X1 16TSSOP

In Stock:: 897

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74LV4052APWRG4 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Discontinued at Mosen
SwitchCircuit:
SP4T
Multiplexer/DemultiplexerCircuit:
4:1
NumberofCircuits:
2
On-StateResistance(Max):
75Ohm
Channel-to-ChannelMatching(ΔRon):
700mOhm
Voltage-SupplySingle(V+):
2V ~ 5.5V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
14ns, 14ns
-3dbBandwidth:
50MHz
ChargeInjection:
-
ChannelCapacitance(CS(off)CD(off)):
0.5pF, 13.1pF
Current-Leakage(IS(off))(Max):
100nA
Crosstalk:
-45dB @ 1MHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
