Texas Instruments SN74LV1T34DCKRG4

Part No.:: SN74LV1T34DCKRG4

Manufacturer:: Texas Instruments

Package:: 5-TSSOP, SC-70-5, SOT-353

Datasheet:: SN74LV1T34DCKRG4.pdf

Description:: IC BUFFER NON-INVERT 5.5V SC70-5

In Stock:: 3028

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74LV1T34DCKRG4 Specifications

Package/Case:
5-TSSOP, SC-70-5, SOT-353
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74LV
ProductStatus:
Discontinued at Mosen
LogicType:
Buffer, Non-Inverting
NumberofElements:
1
NumberofBitsperElement:
1
InputType:
-
OutputType:
Push-Pull
Current-OutputHighLow:
8mA, 8mA
Voltage-Supply:
1.6V ~ 5.5V
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
