Texas Instruments SN74HC74DRE4

Part No.:: SN74HC74DRE4

Manufacturer:: Texas Instruments

Package:: 14-SOIC

Datasheet:: SN74HC74DRE4.pdf

Description:: IC FF D-TYPE DUAL 1BIT 14SOIC

In Stock:: 3084

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74HC74DRE4 Specifications

Packaging:
Tape & Reel (TR)
Series:
74HC
ProductStatus:
Obsolete
Function:
Set(Preset) and Reset
Type:
D-Type
OutputType:
Complementary
NumberofElements:
2
NumberofBitsperElement:
1
ClockFrequency:
60 MHz
MaxPropagationDelay@VMaxCL:
30ns @ 6V, 50pF
TriggerType:
Positive Edge
Current-OutputHighLow:
5.2mA, 5.2mA
Voltage-Supply:
2V ~ 6V
Current-Quiescent(Iq):
4 µA
InputCapacitance:
3 pF
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

SN74HC74DRE4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74HC74DRE4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74HC74DRE4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74HC74DRE4 information

Views：

SN74HC74DRE4 Typical application Circuitry

SN74HC74DRE4

A dual positive-edge triggered D-type flip-flop with clear and preset functions is the SN74HC74DRE4.It is a member of the well-known 74HC series, which uses quick CMOS technology. This chip is frequently utilized in many different applications, such as.

1. Data Storage:It can store bits of information, making it useful in registers, counters, and memory devices.

2. Frequency Dividing:In clock circuits, it's often used for dividing the frequency of a signal.

3. Control Systems: In digital control circuits, it can help in managing the sequence of operations.

Key Features of the SN74HC74DRE4include:

- Operating Voltage Range: Typically from 2V to 6V, which allows for use in low-voltage applications.

- High-Speed Performance: Characterized by fast switching times, suitable for high-speed operations.

- minimal Power Consumption: Battery-powered gadgets require minimal power dissipation, which is why it is developed with that in mind.

Let's consider a simple application scenario:Using the SN74HC74DRE4in a Frequency Divider Circuit.

Specifics of the Circuit Connection:

1. Pin 14, or VCC, should be connected to the positive supply voltage, usually +5V.

2. GND (Pin 7):Connect to the ground.

3. Clock Input (Pins 3 and 11): Connect the clock signal here. This is where the frequency division will be based on.

4. Clear (Pins 1 and 13) and Preset (Pins 4 and 10):To ensure normal operation, tie these pins to VCC. They are active-low inputs.

5. Outputs (Pins 2 and 12 for Q; Pins 5 and 9 for \overline{Q}): These are the outputs of the flip-flops. The frequency at these points will be half of the input clock frequency.

6. Data Inputs (Pins 6 and 8):For a simple frequency divider, tie these to ground.

Design Considerations:

- Input Signal Characteristics: Ensure the clock signal's frequency and voltage levels are compatible with the chip.

- Power Supply Stability: Fluctuations in VCC can affect the performance.

- Decoupling Capacitors: Put a capacitor in close proximity to the VCC pin in order to filter out noise.

- Operating Temperature Range: Consider the environmental conditions as they can impact the chip's functionality.

Using the SN74HC74DRE4in this way demonstrates its utility in digital electronics, especially where reliable and efficient frequency division is needed.This is only one of the many applications for this versatile component.
