Texas Instruments SN74HC541NS

Part No.:: SN74HC541NS

Manufacturer:: Texas Instruments

Package:: 20-SOIC (0.209, 5.30mm Width)

Datasheet:: SN74HC541NS.pdf

Description:: IC BUFFER NON-INVERT 6V 20SO

In Stock:: 2592

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74HC541NS Specifications

Package/Case:
20-SOIC (0.209, 5.30mm Width)
Packaging:
Tube
Series:
74HC
ProductStatus:
Active
LogicType:
Buffer, Non-Inverting
NumberofElements:
1
NumberofBitsperElement:
8
InputType:
-
OutputType:
3-State
Current-OutputHighLow:
7.8mA, 7.8mA
Voltage-Supply:
2V ~ 6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
