Texas Instruments SN74AVC8T245RHLR

Part No.:: SN74AVC8T245RHLR

Manufacturer:: Texas Instruments

Package:: 24-VFQFN Exposed Pad

Datasheet:: SN74AVC8T245RHLR.pdf

Description:: IC TRANSLATION TXRX 3.6V 24VQFN

In Stock:: 3547

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74AVC8T245RHLR Specifications

Package/Case:
24-VFQFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
74AVC
ProductStatus:
Active
LogicType:
Translation Transceiver
NumberofElements:
2
NumberofBitsperElement:
8
InputType:
-
OutputType:
3-State
Current-OutputHighLow:
12mA, 12mA
Voltage-Supply:
1.2V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
