Texas Instruments SN74AVC4T774RSVR

Part No.:: SN74AVC4T774RSVR

Manufacturer:: Texas Instruments

Package:: 16-UFQFN

Datasheet:: SN74AVC4T774RSVR.pdf

Description:: IC TRNSLTR BIDIRECTIONAL 16UQFN

In Stock:: 2174

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74AVC4T774RSVR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74AVC
ProductStatus:
Active
TranslatorType:
Voltage Level
ChannelType:
Bidirectional
NumberofCircuits:
1
ChannelsperCircuit:
4
Voltage-VCCA:
1.2 V ~ 3.6 V
Voltage-VCCB:
1.2 V ~ 3.6 V
InputSignal:
-
OutputSignal:
-
OutputType:
Tri-State, Non-Inverted
DataRate:
380Mbps
OperatingTemperature:
-40°C ~ 85°C (TA)
Features:
-
MountingType:
Surface Mount
