Texas Instruments SN74AUCH16244ZQLR

Part No.:: SN74AUCH16244ZQLR

Manufacturer:: Texas Instruments

Package:: 56-VFBGA

Datasheet:: SN74AUCH16244ZQLR.pdf

Description:: IC BUFFER NON-INVERT 2.7V 56BGA

In Stock:: 2640

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74AUCH16244ZQLR Specifications

Package/Case:
56-VFBGA
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74AUCH
ProductStatus:
Obsolete
LogicType:
Buffer, Non-Inverting
NumberofElements:
4
NumberofBitsperElement:
4
InputType:
-
OutputType:
3-State
Current-OutputHighLow:
9mA, 9mA
Voltage-Supply:
0.8V ~ 2.7V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
