Texas Instruments SN74ALVC164245DLR

Part No.:: SN74ALVC164245DLR

Manufacturer:: Texas Instruments

Package:: 48-BSSOP (0.295, 7.50mm Width)

Datasheet:: SN74ALVC164245DLR.pdf

Description:: IC TRNSLTR BIDIRECTIONAL 48SSOP

In Stock:: 2395

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74ALVC164245DLR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74ALVC
ProductStatus:
Active
TranslatorType:
Voltage Level
ChannelType:
Bidirectional
NumberofCircuits:
2
ChannelsperCircuit:
8
Voltage-VCCA:
2.3 V ~ 3.6 V
Voltage-VCCB:
3 V ~ 5.5 V
InputSignal:
-
OutputSignal:
-
OutputType:
Tri-State, Non-Inverted
DataRate:
-
OperatingTemperature:
-40°C ~ 85°C (TA)
Features:
-
MountingType:
Surface Mount
