Texas Instruments SN74AHC1G14DCKRG4

Part No.:: SN74AHC1G14DCKRG4

Manufacturer:: Texas Instruments

Package:: SC-70-5

Datasheet:: SN74AHC1G14DCKRG4.pdf

Description:: IC INVERT SCHMITT 1CH 1IN SC70

In Stock:: 2920

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74AHC1G14DCKRG4 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74AHC
ProductStatus:
Discontinued at Mosen
LogicType:
Inverter
NumberofCircuits:
1
NumberofInputs:
1
Features:
Schmitt Trigger
Voltage-Supply:
2V ~ 5.5V
Current-Quiescent(Max):
1 µA
Current-OutputHighLow:
8mA, 8mA
LogicLevel-Low:
0.9V ~ 1.65V
LogicLevel-High:
2.2V ~ 3.85V
MaxPropagationDelay@VMaxCL:
10.6ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

SN74AHC1G14DCKRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74AHC1G14DCKRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74AHC1G14DCKRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74AHC1G14DCKRG4 information

Views：

SN74AHC1G14DCKRG4 Typical application Circuitry

SN74AHC1G14DCKRG4

The SN74AHC1G14DCKRG4 is an integrated circuit (IC) that functions as a single Schmitt-trigger inverter. This type of chip is commonly used in digital applications to provide noise immunity and shape irregular input waveforms into defined, sharp output signals. It is particularly useful in applications where signals are subject to noise or slow rise and fall times.

Key Features of SN74AHC1G14DCKRG4:

- Operating Voltage Range: Typically, this IC operates within a range of 2V to 5.5V, making it suitable for various low-power applications.

- Schmitt-Trigger Action: The Schmitt-trigger input provides a hysteresis effect, which means that the switching threshold levels change depending on whether the output is transitioning from high to low or low to high. This characteristic is vital for cleaning up noisy input signals.

- High-Speed Operation: With a typical propagation delay significantly low, it is suitable for high-speed operations.

- Low Power Consumption: Because of its low power needs, it is perfect for low-power and battery-operated devices.

Application Scenario: Signal Conditioning in a Microcontroller Input

Circuit Connection:

1. Power Supply Connection: Attach the GND pin (pin 2) to the ground and the VCC pin (pin 5) to a +3.3V power source. This ensures the IC operates in its standard voltage range.

2. Input Signal Connection: Connect an external signal (e.g., from a sensor) to the A input pin (pin 4). This signal is the one you want to clean up or shape.

3. Output Signal Connection: Connect the Y output pin (pin 1) to a microcontroller's digital input pin. The output from the SN74AHC1G14DCKRG4 will be a clean, inverted version of the input signal.

4. Pull-up/Pull-down Resistors: Depending on the microcontroller's logic level requirements, you might need to use pull-up or pull-down resistors on the output pin.

Design Considerations:

- Input Signal Characteristics: Ensure that the input signal characteristics (voltage level, frequency) are within the IC's operating limits.

- Power Supply Decoupling: Use a decoupling capacitor near the power supply pins to filter out noise from the power supply.

- Temperature and Environmental Factors: The performance of the integrated circuit might be impacted by the operating temperature range and environmental factors.

- PCB Layout: To reduce electromagnetic interference and crosstalk, careful PCB layout design is necessary.

In summary, the SN74AHC1G14DCKRG4 is a versatile component used for signal conditioning, particularly in digital systems where noise immunity and signal integrity are critical. Its low power consumption, high-speed operation, and Schmitt-trigger action make it an ideal choice for applications like microcontroller input signal conditioning. When designing circuits with this IC, it's important to consider factors like input signal characteristics, power supply stability, and environmental conditions.
