Texas Instruments SN74AHC1G14DBVR

Part No.:: SN74AHC1G14DBVR

Manufacturer:: Texas Instruments

Package:: SOT-23-5

Datasheet:: SN74AHC1G14DBVR.pdf

Description:: IC INVERTER 1CH 1-INP SOT23-5

In Stock:: 2903

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74AHC1G14DBVR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
74AHC
ProductStatus:
Active
LogicType:
Inverter
NumberofCircuits:
1
NumberofInputs:
1
Features:
Schmitt Trigger
Voltage-Supply:
2V ~ 5.5V
Current-Quiescent(Max):
1 µA
Current-OutputHighLow:
8mA, 8mA
LogicLevel-Low:
0.9V ~ 1.65V
LogicLevel-High:
2.2V ~ 3.85V
MaxPropagationDelay@VMaxCL:
10.6ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

SN74AHC1G14DBVR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74AHC1G14DBVR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74AHC1G14DBVR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74AHC1G14DBVR information

Views：

SN74AHC1G14DBVR Typical application Circuitry

SN74AHC1G14DBVR

The SN74AHC1G14DBVR is an integrated circuit chip, specifically a single Schmitt-trigger inverter. Digital electronics frequently use this kind of chip. Let's delve into its functions, applications, key parameters, and a detailed application circuit example.

Function and Application Scenarios:

SN74AHC1G14DBVR is primarily used for:

1. Signal Conditioning: Improves signal quality by transforming an analog signal into a clean digital signal.

2. Pulse Shaping: Converts noisy or irregular input pulses into well-defined output pulses.

2. Logic Level Conversion: Adapts between different logic levels, particularly useful in mixed-voltage environments.

Key Parameters:

1. Voltage Range: Typically operates between 2V and 5.5V.

2. High-Speed Operation: Offers fast switching characteristics.

3. Low Power Consumption: Suitable for battery-powered applications.

Application Circuit Example: Noise Filtering in a Digital Input

Noise Filtering in a Digital Input:

1. Input Connection (Pin 1): Connect the noisy digital signal to this pin.

2. Vcc and Ground (Pins 5 and 4): Connect to a 5V power supply and ground, respectively.

3. Output (Pin 2): Extracts the cleaned-up digital signal from here.

4. Decoupling Capacitor (Across Vcc and Ground): A small capacitor (e.g., 0.1 μF) should be placed close to the chip to stabilize the power supply.

Design-Related Issues:

When creating a circuit using SN74AHC1G14DBVR, take into account:

1. Power Supply Stability: Ensure a stable voltage source to avoid erratic behavior.

2. Signal Characteristics: Match the input signal characteristics with the chip's specifications.

3. Decoupling Capacitor: Always include a decoupling capacitor to reduce noise in the power supply.

4. Temperature and Environmental Factors: Be aware of the operating temperature range and environmental conditions where the circuit will be used.

In summary, the SN74AHC1G14DBVR serves crucial roles in digital signal processing, offering versatility in various applications, especially where signal integrity and low power are essential. Its application in noise filtering is a testament to its utility in enhancing signal quality in digital systems.
