Texas Instruments SN74AHC1G08DBVRE4

Part No.:: SN74AHC1G08DBVRE4

Manufacturer:: Texas Instruments

Package:: SOT-23-5

Datasheet:: SN74AHC1G08DBVRE4.pdf

Description:: IC GATE AND 1CH 2-INP SOT23-5

In Stock:: 3354

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74AHC1G08DBVRE4 Specifications

Packaging:
Tape & Reel (TR)
Series:
74AHC
ProductStatus:
Discontinued at Mosen
LogicType:
AND Gate
NumberofCircuits:
1
NumberofInputs:
2
Features:
-
Voltage-Supply:
2V ~ 5.5V
Current-Quiescent(Max):
1 µA
Current-OutputHighLow:
8mA, 8mA
LogicLevel-Low:
0.5V ~ 1.65V
LogicLevel-High:
1.5V ~ 3.85V
MaxPropagationDelay@VMaxCL:
7.9ns @ 5V, 50pF
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Surface Mount
