Texas Instruments SN74AHC1G00DCKRE4

Part No.:: SN74AHC1G00DCKRE4

Manufacturer:: Texas Instruments

Package:: SC-70-5

Datasheet:: SN74AHC1G00DCKRE4.pdf

Description:: IC GATE NAND 1CH 2-INP SC70-5

In Stock:: 3524

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74AHC1G00DCKRE4 Specifications

Packaging:
Tape & Reel (TR)
Series:
74AHC
ProductStatus:
Discontinued at Mosen
LogicType:
NAND Gate
NumberofCircuits:
1
NumberofInputs:
2
Features:
-
Voltage-Supply:
2V ~ 5.5V
Current-Quiescent(Max):
1 µA
Current-OutputHighLow:
8mA, 8mA
LogicLevel-Low:
0.5V ~ 1.65V
LogicLevel-High:
1.5V ~ 3.85V
MaxPropagationDelay@VMaxCL:
7.5ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

SN74AHC1G00DCKRE4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74AHC1G00DCKRE4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74AHC1G00DCKRE4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74AHC1G00DCKRE4 information

Views：

SN74AHC1G00DCKRE4 Typical application Circuitry

SN74AHC1G00DCKRE4

The SN74AHC1G00DCKRE4 is a type of digital logic chip known as a single 2-input positive-NAND gate.Let's examine this chip's features, uses, important specifications, and an example circuit design that takes these factors into account.

Functionality:

The SN74AHC1G00DCKRE4 operates as a NAND gate, which outputs a low signal only when both inputs are high. Every other time, there is a high output. This basic logic function is fundamental in digital electronics.

Application Scenarios:

NAND gates like the SN74AHC1G00DCKRE4 are widely used in various digital circuits, including:

- Digital Logic Circuits: Forming the building blocks of complex logic functions.

- Control Systems: Used in microcontrollers and other control circuitry.

- Signal Processing: Integral in processing digital signals in various electronic devices.

Parameter Features:

Key parameters of the SN74AHC1G00DCKRE4 include:

- Voltage Range: Typically operates at 2 V to 5.5 V.

- Output Current: Capable of driving moderate loads.

- Propagation Delay: Fast response time, suitable for high-speed operations.

Example Circuit: Logic Control in a Microcontroller System

Circuit Design: Consider a scenario where the SN74AHC1G00DCKRE4 is used for logic control in a microcontroller system.

1. Power Supply: Connect VCC (pin 5) to a 5V supply, and GND (pin 2) to ground.

2. Input Signals: Connect two digital inputs to A (pin 1) and B (pin 6). These could be from GPIOs of a microcontroller.

3. Output Connection: The output (pin 4) goes to another part of the circuit or back to the microcontroller for further processing.

4. Pull-up/Pull-down Resistors: Depending on the circuit, use pull-up or pull-down resistors on the inputs to ensure defined logic levels when inputs are floating.

5. Decoupling Capacitor: To stabilize the power supply, place a tiny capacitor (0.1 µF, for example) between VCC and GND close to the chip.

Design Considerations:

- Voltage Compatibility: Ensure that the input and output voltages are compatible with other components in the system.

- Input Impedance: Consider the impedance of inputs to avoid loading effects.

- Speed Requirements: Match the propagation delay of the gate with the timing requirements of the system.

Incorporating the SN74AHC1G00DCKRE4 into a microcontroller system for logic control demonstrates its versatility and functionality in digital electronics. This example outlines how to connect and consider various aspects of using this NAND gate in a practical application.
