Texas Instruments SN74AHC1G00DBVR

Part No.:: SN74AHC1G00DBVR

Manufacturer:: Texas Instruments

Package:: SOT-23-5

Datasheet:: SN74AHC1G00DBVR.pdf

Description:: IC GATE NAND 1CH 2-INP SOT23-5

In Stock:: 4959

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74AHC1G00DBVR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74AHC
ProductStatus:
Active
LogicType:
NAND Gate
NumberofCircuits:
1
NumberofInputs:
2
Features:
-
Voltage-Supply:
2V ~ 5.5V
Current-Quiescent(Max):
1 µA
Current-OutputHighLow:
8mA, 8mA
LogicLevel-Low:
0.5V ~ 1.65V
LogicLevel-High:
1.5V ~ 3.85V
MaxPropagationDelay@VMaxCL:
7.5ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

SN74AHC1G00DBVR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74AHC1G00DBVR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74AHC1G00DBVR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74AHC1G00DBVR information

Views：

SN74AHC1G00DBVR Typical application Circuitry

SN74AHC1G00DBVR

The SN74AHC1G00DBVR is a type of digital logic chip known as a NAND gate. It is part of the 74AHC series, which are known for their high-speed and low-power consumption characteristics. An outline of its functions, uses, and a thorough application scenario are provided below.

Characteristics of the SN74AHC1G00DBVR:

Voltage Range of Operation: With its usual operating range of 2 V to 5.5 V, this chip can be used with a variety of digital systems.

- Output Drive Capability: It can drive outputs with considerable current, suitable for driving LEDs or other low-power devices directly.

- Low Power Consumption: The SN74AHC1G00DBVR consumes very little power, which is ideal for battery-operated devices.

- High-Speed Operation: It is capable of high-speed operation, making it useful in systems where response time is critical.

Application Scenarios:

- Digital Logic Circuits: It is widely used in complex digital circuits for implementing logic functions.

- Control Systems: In control systems, it can be used to make decisions based on the combination of multiple input signals.

- Signal Processing: Used in signal processing circuits for manipulating digital signals.

Detailed Application Scenario: Creating a Simple Security System

Objective: Utilizing the SN74AHC1G00DBVR in a simple security system where the circuit triggers an alarm when two conditions are met simultaneously.

Circuit Establishment:

1. Power Supply Connection: Attach the SN74AHC1G00DBVR's Vcc pin to a 5V power source. Attach the GND pin to the ground.

2. Input Signals: Connect two sensors (e.g., motion and door sensors) to the two input pins of the SN74AHC1G00DBVR. Let's say these are pins 1 and 2.

3. Output to Alarm: Connect the output pin (pin 3) of the SN74AHC1G00DBVR to the input of an alarm system. When both sensors are triggered, the output will go low, activating the alarm.

Design Considerations:

- Power Stability: Make sure there are no variations in the power supply, as this could impact the chip's functionality.

- Signal Noise: Minimize noise in the input signals for accurate triggering of the alarm.

- Heat Dissipation: Although the chip consumes low power, proper heat dissipation should be considered in the design to prevent overheating.

In summary, the SN74AHC1G00DBVR is a versatile and efficient NAND gate useful in a variety of applications, especially where compact size and low power consumption are required. Its application in a simple security system demonstrates its utility in practical scenarios. When designing circuits with the SN74AHC1G00DBVR, it's crucial to consider power supply stability, signal integrity, and thermal management.
