Texas Instruments SN74ACT14DRG4

Part No.:: SN74ACT14DRG4

Manufacturer:: Texas Instruments

Package:: 14-SOIC

Datasheet:: SN74ACT14DRG4.pdf

Description:: IC INV SCHMITT 6CH 1-IN 14SOIC

In Stock:: 2662

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74ACT14DRG4 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74ACT
ProductStatus:
Discontinued at Mosen
LogicType:
Inverter
NumberofCircuits:
6
NumberofInputs:
1
Features:
Schmitt Trigger
Voltage-Supply:
4.5V ~ 5.5V
Current-Quiescent(Max):
2 µA
Current-OutputHighLow:
24mA, 24mA
LogicLevel-Low:
0.5V ~ 1.4V
LogicLevel-High:
1.2V ~ 2.1V
MaxPropagationDelay@VMaxCL:
11.5ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

SN74ACT14DRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74ACT14DRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74ACT14DRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74ACT14DRG4 information

Views：

SN74ACT14DRG4 Typical application Circuitry

SN74ACT14DRG4

The SN74ACT14DRG4 is a hex schmitt-trigger inverter integrated circuit, known for its specific features and diverse applications in digital electronics. Let's delve into its functionality, application scenarios, parameters, and a detailed example of its application in a circuit design.

Functionality of SN74ACT14DRG4:

The SN74ACT14DRG4 chip is primarily used as a hex schmitt-trigger inverter. This means it contains six independent inverters with Schmitt-trigger action on each input. The Schmitt-trigger feature allows the chip to transform an irregular or noisy input signal into a clean, digital output signal, making it extremely useful in digital circuits where signal integrity is crucial.

Use Cases:

Due to its adaptability, this chip can be utilized in a variety of situations, such as:

- Signal Conditioning: Cleaning up noisy signals in digital communication.

- Wave Shaping: Generating precise waveforms from irregular inputs.

- Debouncing Switches: Eliminating noise from mechanical switch inputs.

Features of Parameters:

The following are important SN74ACT14DRG4 parameters:

- Supply Voltage Range: Typically 4.5V to 5.5V.

- High-Speed Operation: With propagation delays significantly low.

- Output Drive Capability: Capable of driving up to 8 LS-TTL loads.

- Temperature Range: Functionally operational over a wide temperature range.

Circuit Implementation: Signal Conditioning

Let's consider a detailed application in signal conditioning.

Circuit Configuration:

1. Input Connection: The input signal, possibly noisy, is connected to one of the inverter inputs, say pin 1 of the SN74ACT14DRG4.

2. Power Supply: Connect VCC (pin 14) to a 5V supply and GND (pin 7) to the ground.

3. Output: The output at pin 2 will be the cleaned-up version of the input signal.

Programming Pins:

- There are no programmable or burnable pins in this IC as it's not a microcontroller or programmable logic device.

Design Considerations:

When designing circuits with the SN74ACT14DRG4, consider:

- Power Supply Stability: Ensure a stable 5V supply.

- Input Signal Characteristics: Understand the nature of the input signal for effective cleaning.

- Load on Output: Ensure the connected load matches the output drive capabilities.

In summary, the SN74ACT14DRG4 is a hex schmitt-trigger inverter useful in numerous digital applications, especially where signal integrity is a concern. Its application in signal conditioning is a prime example of its utility, showcasing its ability to clean up noisy signals effectively. When designing with this IC, careful consideration of power supply, signal characteristics, and load capacities is crucial.
